Ductile Iron Threaded Ball Valves 1000PSI 2000PSI

Product Attributes

Model No.: DIBV

Brand: OEM

Types Of: Ball Valves

Support Customization: Oem

Place Of Origin: China

Application: General

Medium Temperature: Medium Temperature

Power: Manual

Flow Medium: Oil

Structure: Ball

Product Description

2 -pc threaded ball valve1000 PSI regular port threaded A395 ductile iron body, chrome plated ball, carbon steel stem, nylon seats, Buna-N seal. Fire safe bare stem with locking device

• Full Port: 1''2''3''4''

• Reduced Port:2''3''4''

• Body: A395 Ductile Iron

• Stem: SS316

• Seat: RPTFE

• Seal: Viton,Buna N,HNBR

• END: ASME B1.20.1 NPT/API 5B(LP)

• Grease Zerw:Copper

  Product Information
  Type	Floating
  Size	1''2''3''4'' I
  Port	Reduced
  Style	2 Piece
  Trim	Chrome Plated Ball & Carbon Steel Stem
  End Connection	Threaded
  Pressure/Class	800PSI 1000 PSI 1500PSI
  Body Spec	A395
  Body Material	Ductile Iron
  Compliance	Fire Safe
  Soft Goods	Buna-N Seals
  Seat Material	Nylon
  Special Service Conditions	Fire Safe
  Operation	Manual
  Series	DIBV

Fig # EUECBV Series

CARBON STEEL EUE END Ball Valve

- Full Port
- Size:  2-3/8''    2-7/8''
-CWP: 2000PSI 3600PSI
- Blow-out Proof Stem
- Boday: ASTM A216 WCB
- Locking Handle
- NACE MR-01-75
- Inspection and Test Acc. to API 598

Fig # EUECBV Series

FORGED STEEL Oilfield Ball Valve

- Full Port/
- Size:1''2''3''4''
-CWP: 3000WOG/5000WOG
- Blow-out Proof Stem
- Delrin /Peek SEAT
- Locking Handle
- NACE MR-01-75
- Inspection and Test Acc. to API 598

Fig # F3E Series

EUE OIL FIELD BALL VALVE

- Full Port
- Size: 2-3/8'' 2-7/8''
-CWP: 2000PSI 3600PSI
- Blow-out Proof Stem
- Boday: ASTM A105, F304,.F316,
- Locking Handle
- Inspection and Test Acc. to API 598
